Data source representing a USD gprim. More...

Inheritance diagram for UsdImagingDataSourceGprim:

Public Member Functions
	HD_DECLARE_DATASOURCE (UsdImagingDataSourceGprim)

bool	Has (const TfToken &name) override
	Returns whether or not this data source can return a meaningful data source for `name`. More...

TfTokenVector	GetNames () override
	Returns the names for which this data source can return meaningful results. More...

HdDataSourceBaseHandle	Get (const TfToken &name) override
	Returns the data source representing `name`, if valid. More...

Public Member Functions inherited from UsdImagingDataSourcePrim
	HD_DECLARE_DATASOURCE (UsdImagingDataSourcePrim)

USDIMAGING_API bool	Has (const TfToken &name) override
	Returns whether or not this data source can return a meaningful data source for `name`. More...

USDIMAGING_API TfTokenVector	GetNames () override
	Returns the names for which this data source can return meaningful results. More...

USDIMAGING_API HdDataSourceBaseHandle	Get (const TfToken &name) override
	Returns the data source representing `name`, if valid. More...

Public Member Functions inherited from HdContainerDataSource
	HD_DECLARE_DATASOURCE_ABSTRACT (HdContainerDataSource)

Protected Member Functions
	UsdImagingDataSourceGprim (const SdfPath &sceneIndexPath, UsdPrim usdPrim, const UsdImagingDataSourceStageGlobals &stageGlobals)
	Use to construct a new UsdImagingDataSourceGprim. More...

void	_AddCustomPrimvar (const TfToken &primvarName, const TfToken &attrName)
	Used by derived classes to add primvars not in the primvars: namespace, e.g. More...

Protected Member Functions inherited from UsdImagingDataSourcePrim
USDIMAGING_API	UsdImagingDataSourcePrim (const SdfPath &sceneIndexPath, UsdPrim usdPrim, const UsdImagingDataSourceStageGlobals &stageGlobals)
	Use to construct a new UsdImagingDataSourcePrim. More...

const SdfPath &	_GetSceneIndexPath () const

const UsdPrim &	_GetUsdPrim () const

const UsdImagingDataSourceStageGlobals &	_GetStageGlobals () const

Additional Inherited Members
Static Public Member Functions inherited from UsdImagingDataSourcePrim
static USDIMAGING_API HdDataSourceLocatorSet	Invalidate (const TfToken &subprim, const TfTokenVector &properties)
	Returns the hydra attribute set we should invalidate if the value of the USD properties in `properties` change. More...

Static Public Member Functions inherited from HdContainerDataSource
static HD_API HdDataSourceBaseHandle	Get (const Handle &container, const HdDataSourceLocator &locator)
	A convenience function: given `container`, return the descendant identified by `locator`, which may be at any depth. More...

Detailed Description

Data source representing a USD gprim.

This is the common base for geometric types and includes features such as materials and primvars.

Definition at line 42 of file dataSourceGprim.h.

Constructor & Destructor Documentation

◆ UsdImagingDataSourceGprim()

UsdImagingDataSourceGprim	(	const SdfPath &	sceneIndexPath,
		UsdPrim	usdPrim,
		const UsdImagingDataSourceStageGlobals &	stageGlobals
	)

protected

Use to construct a new UsdImagingDataSourceGprim.

sceneIndexPath is the path of this object in the scene index.

usdPrim is the USD prim object that this data source represents.

stageGlobals represents the context object for the UsdStage with which to evaluate this attribute data source.

Note: client code calls this via static New.

Member Function Documentation

◆ _AddCustomPrimvar()

void _AddCustomPrimvar	(	const TfToken &	primvarName,
		const TfToken &	attrName
	)

protected

Used by derived classes to add primvars not in the primvars: namespace, e.g.

"points" and "normals". Interpolation is taken from metadata, or hardcoded to "vertex" for points. Note that this needs to be called before Get("primvars") in order to take effect.

primvarName the name of the primvar in the scene index representation

attrName the name of a USD attribute to supply data for the primvar; data will come from _GetUsdPrim().GetAttribute(attrName);
