Basic Sdf data types. More...

This graph shows which files directly or indirectly include this file:

Classes
class	SdfUnregisteredValue
	Stores a representation of the value for an unregistered metadata field encountered during text layer parsing. More...

class	SdfValueBlock
	A special value type that can be used to explicitly author an opinion for an attribute's default value or time sample value that represents having no value. More...

Macros
#define	_SDF_LENGTH_UNITS

#define	_SDF_ANGULAR_UNITS

#define	_SDF_DIMENSIONLESS_UNITS

#define	_SDF_UNITS

#define	_SDF_UNIT_TAG(tup) BOOST_PP_TUPLE_ELEM(3, 0, tup)

#define	_SDF_UNIT_NAME(tup) BOOST_PP_TUPLE_ELEM(3, 1, tup)

#define	_SDF_UNIT_SCALE(tup) BOOST_PP_TUPLE_ELEM(3, 2, tup)

#define	_SDF_UNITSLIST_CATEGORY(tup) BOOST_PP_TUPLE_ELEM(2, 0, tup)

#define	_SDF_UNITSLIST_TUPLES(tup) BOOST_PP_TUPLE_ELEM(2, 1, tup)

#define	_SDF_UNITSLIST_ENUM(elem)

#define	_SDF_DECLARE_UNIT_ENUMERANT(r, tag, elem) BOOST_PP_CAT(Sdf ## tag ## Unit, _SDF_UNIT_TAG(elem)),

#define	_SDF_DECLARE_UNIT_ENUM(r, unused, elem)

#define	_SDF_MAX_UNITS_OP(d, state, list) BOOST_PP_MAX_D(d, state, BOOST_PP_SEQ_SIZE(_SDF_UNITSLIST_TUPLES(list)))

#define	_SDF_UNIT_MAX_UNITS BOOST_PP_LIST_FOLD_LEFT(_SDF_MAX_UNITS_OP, 0, _SDF_UNITS)

#define	_SDF_UNIT_NUM_TYPES BOOST_PP_LIST_SIZE(_SDF_UNITS)

#define	_SDF_UNIT_MAX_UNITS_BITS TF_BITS_FOR_VALUES(_SDF_UNIT_MAX_UNITS)

#define	_SDF_UNIT_TYPES_BITS TF_BITS_FOR_VALUES(_SDF_UNIT_NUM_TYPES)

#define	_SDF_SCALAR_VALUE_TYPES

#define	_SDF_DIMENSIONED_VALUE_TYPES

#define	SDF_VALUE_TYPES _SDF_SCALAR_VALUE_TYPES _SDF_DIMENSIONED_VALUE_TYPES

#define	SDF_VALUE_CPP_TYPE(tup) BOOST_PP_TUPLE_ELEM(4, 2, tup)

#define	SDF_VALUE_CPP_ARRAY_TYPE(tup) VtArray<BOOST_PP_TUPLE_ELEM(4, 2, tup)>

#define	SDF_DECLARE_VALUE_TYPE_TRAITS(r, unused, elem)

#define	SDF_VALUE_ROLE_NAME_TOKENS

Typedefs
typedef std::map< std::string, VtValue >	SdfMapperParametersMap
	A map of mapper parameter names to parameter values. More...

typedef std::map< std::string, std::string >	SdfVariantSelectionMap
	A map of reference variant set names to variants in those sets. More...

typedef std::map< std::string, std::vector< std::string > >	SdfVariantsMap
	A map of variant set names to list of variants in those sets. More...

typedef std::map< SdfPath, SdfPath >	SdfRelocatesMap
	A map of source SdfPaths to target SdfPaths for relocation. More...

typedef std::map< double, VtValue >	SdfTimeSampleMap
	A map from sample times to sample values. More...

typedef std::map< std::string, SdfVariantSetSpecHandle >	SdfVariantSetSpecHandleMap

Enumerations
enum	SdfSpecType { SdfSpecTypeUnknown = 0, SdfSpecTypeAttribute, SdfSpecTypeConnection, SdfSpecTypeExpression, SdfSpecTypeMapper, SdfSpecTypeMapperArg, SdfSpecTypePrim, SdfSpecTypePseudoRoot, SdfSpecTypeRelationship, SdfSpecTypeRelationshipTarget, SdfSpecTypeVariant, SdfSpecTypeVariantSet, SdfNumSpecTypes }
	An enum that specifies the type of an object. More...

enum	SdfSpecifier { SdfSpecifierDef, SdfSpecifierOver, SdfSpecifierClass, SdfNumSpecifiers }
	An enum that identifies the possible specifiers for an SdfPrimSpec. More...

enum	SdfPermission { SdfPermissionPublic, SdfPermissionPrivate, SdfNumPermissions }
	An enum that defines permission levels. More...

enum	SdfVariability { SdfVariabilityVarying, SdfVariabilityUniform, SdfNumVariabilities }
	An enum that identifies variability types for attributes. More...

enum	SdfAuthoringError { SdfAuthoringErrorUnrecognizedFields, SdfAuthoringErrorUnrecognizedSpecType }
	An enum for TfError codes related to authoring operations. More...

Functions
bool	SdfIsDefiningSpecifier (SdfSpecifier spec)
	Returns true if the specifier defines a prim. More...

SDF_API TfEnum	SdfDefaultUnit (TfToken const &typeName)
	Gets the show default unit for the given /a typeName. More...

SDF_API const TfEnum &	SdfDefaultUnit (const TfEnum &unit)
	Gets the show default unit for the given /a unit. More...

SDF_API const std::string &	SdfUnitCategory (const TfEnum &unit)
	Gets the unit category for a given /a unit. More...

SDF_API double	SdfConvertUnit (const TfEnum &fromUnit, const TfEnum &toUnit)
	Converts from one unit of measure to another. More...

SDF_API const std::string &	SdfGetNameForUnit (const TfEnum &unit)
	Gets the name for a given /a unit. More...

SDF_API const TfEnum &	SdfGetUnitFromName (const std::string &name)
	Gets a unit for the given /a name. More...

SDF_API bool	SdfValueHasValidType (VtValue const &value)
	Given a value, returns if there is a valid corresponding valueType. More...

SDF_API TfType	SdfGetTypeForValueTypeName (TfToken const &name)
	Given an sdf valueType name, produce TfType if the type name specifies a valid sdf value type. More...

SDF_API SdfValueTypeName	SdfGetValueTypeNameForValue (VtValue const &value)
	Given a value, produce the sdf valueType name. More...

SDF_API TfToken	SdfGetRoleNameForValueTypeName (TfToken const &typeName)
	Return role name for `typeName`. More...

	BOOST_PP_SEQ_FOR_EACH (SDF_DECLARE_VALUE_TYPE_TRAITS, ~, SDF_VALUE_TYPES)

SDF_API bool	SdfConvertToValidMetadataDictionary (VtDictionary dict, std::string errMsg)
	Convert `dict` to a valid metadata dictionary for scene description. More...

	TF_DECLARE_PUBLIC_TOKENS (SdfValueRoleNames, SDF_API, SDF_VALUE_ROLE_NAME_TOKENS)

	SDF_DECLARE_HANDLES (SdfLayer)

	SDF_DECLARE_HANDLES (SdfAttributeSpec)

	SDF_DECLARE_HANDLES (SdfPrimSpec)

	SDF_DECLARE_HANDLES (SdfPropertySpec)

	SDF_DECLARE_HANDLES (SdfSpec)

	SDF_DECLARE_HANDLES (SdfRelationshipSpec)

	SDF_DECLARE_HANDLES (SdfVariantSetSpec)

	SDF_DECLARE_HANDLES (SdfVariantSpec)

SDF_API std::ostream &	operator<< (std::ostream &out, const SdfSpecifier &spec)
	Writes the string representation of `SdfSpecifier` to out. More...

SDF_API std::ostream &	operator<< (std::ostream &out, const SdfRelocatesMap &reloMap)
	Writes the string representation of `SdfRelocatesMap` to out. More...

SDF_API std::ostream &	operator<< (std::ostream &out, const SdfTimeSampleMap &sampleMap)
	Writes the string representation of `SdfTimeSampleMap` to out. More...

SDF_API std::ostream &	VtStreamOut (const SdfVariantSelectionMap &, std::ostream &)

SDF_API std::ostream &	operator<< (std::ostream &out, const SdfUnregisteredValue &value)
	Writes the string representation of `SdfUnregisteredValue` to out. More...

SDF_API std::ostream &	operator<< (std::ostream &, SdfValueBlock const &)

SDF_API std::ostream &	operator<< (std::ostream &out, const SdfHumanReadableValue &hrval)

SDF_API size_t	hash_value (const SdfHumanReadableValue &hrval)

Variables
SDF_API TfStaticData< const Sdf_ValueTypeNamesType, Sdf_ValueTypeNamesType::_Init >	SdfValueTypeNames

Detailed Description

Basic Sdf data types.

Definition in file types.h.

Macro Definition Documentation

◆ _SDF_ANGULAR_UNITS

#define _SDF_ANGULAR_UNITS

Value:

((Degrees, "deg", 1.0)) \

((Radians, "rad", 57.2957795130823208768))

Definition at line 231 of file types.h.

◆ _SDF_DECLARE_UNIT_ENUM

#define _SDF_DECLARE_UNIT_ENUM	(	r,
		unused,
		elem
	)

Value:

enum _SDF_UNITSLIST_ENUM(elem) {                         \
    BOOST_PP_SEQ_FOR_EACH(_SDF_DECLARE_UNIT_ENUMERANT,   \
                          _SDF_UNITSLIST_CATEGORY(elem), \
                          _SDF_UNITSLIST_TUPLES(elem))   \
};

Definition at line 257 of file types.h.

◆ _SDF_DIMENSIONED_VALUE_TYPES

#define _SDF_DIMENSIONED_VALUE_TYPES

Value:

((Matrix2d,   matrix2d,   GfMatrix2d,     (2,2) )) \
    ((Matrix3d,   matrix3d,   GfMatrix3d,     (3,3) )) \
    ((Matrix4d,   matrix4d,   GfMatrix4d,     (4,4) )) \
    ((Quath,      quath,      GfQuath,        (4)   )) \
    ((Quatf,      quatf,      GfQuatf,        (4)   )) \
    ((Quatd,      quatd,      GfQuatd,        (4)   )) \
    ((Int2,       int2,       GfVec2i,        (2)   )) \
    ((Half2,      half2,      GfVec2h,        (2)   )) \
    ((Float2,     float2,     GfVec2f,        (2)   )) \
    ((Double2,    double2,    GfVec2d,        (2)   )) \
    ((Int3,       int3,       GfVec3i,        (3)   )) \
    ((Half3,      half3,      GfVec3h,        (3)   )) \
    ((Float3,     float3,     GfVec3f,        (3)   )) \
    ((Double3,    double3,    GfVec3d,        (3)   )) \
    ((Int4,       int4,       GfVec4i,        (4)   )) \
    ((Half4,      half4,      GfVec4h,        (4)   )) \
    ((Float4,     float4,     GfVec4f,        (4)   )) \
    ((Double4,    double4,    GfVec4d,        (4)   ))

Definition at line 359 of file types.h.

◆ _SDF_DIMENSIONLESS_UNITS

#define _SDF_DIMENSIONLESS_UNITS

Value:

((Percent, "%", 0.01)) \

((Default, "default", 1.0))

Definition at line 235 of file types.h.

◆ _SDF_LENGTH_UNITS

#define _SDF_LENGTH_UNITS

Value:

((Millimeter, "mm",  0.001))    \
((Centimeter, "cm",  0.01))     \
((Decimeter,  "dm",  0.1))      \
((Meter,      "m",   1.0))      \
((Kilometer,  "km",  1000.0))   \
((Inch,       "in",  0.0254))   \
((Foot,       "ft",  0.3048))   \
((Yard,       "yd",  0.9144))   \
((Mile,       "mi",  1609.344))

Definition at line 220 of file types.h.

◆ _SDF_SCALAR_VALUE_TYPES

#define _SDF_SCALAR_VALUE_TYPES

Value:

((Bool,       bool,       bool,           ()    )) \
    ((UChar,      uchar,      unsigned char,  ()    )) \
    ((Int,        int,        int,            ()    )) \
    ((UInt,       uint,       unsigned int,   ()    )) \
    ((Int64,      int64,      int64_t,        ()    )) \
    ((UInt64,     uint64,     uint64_t,       ()    )) \
    ((Half,       half,       GfHalf,         ()    )) \
    ((Float,      float,      float,          ()    )) \
    ((Double,     double,     double,         ()    )) \
    ((TimeCode,   timecode,   SdfTimeCode,    ()    )) \
    ((String,     string,     std::string,    ()    )) \
    ((Token,      token,      TfToken,        ()    )) \
    ((Asset,      asset,      SdfAssetPath,   ()    )) \
    ((Opaque,     opaque,     SdfOpaqueValue, ()    ))

Definition at line 343 of file types.h.

◆ _SDF_UNITS

#define _SDF_UNITS

Value:

((Length, _SDF_LENGTH_UNITS),               \
((Angular, _SDF_ANGULAR_UNITS),             \
((Dimensionless, _SDF_DIMENSIONLESS_UNITS), \
 BOOST_PP_NIL)))

Definition at line 239 of file types.h.

◆ _SDF_UNITSLIST_ENUM

#define _SDF_UNITSLIST_ENUM ( elem )

Value:

BOOST_PP_CAT(BOOST_PP_CAT(Sdf, \

_SDF_UNITSLIST_CATEGORY(elem)), Unit)

Definition at line 251 of file types.h.

◆ SDF_DECLARE_VALUE_TYPE_TRAITS

#define SDF_DECLARE_VALUE_TYPE_TRAITS	(	r,
		unused,
		elem
	)

Value:

template <>                                                                 \
struct SdfValueTypeTraits<SDF_VALUE_CPP_TYPE(elem)> {                       \
    static const bool IsValueType = true;                                   \
};                                                                          \
template <>                                                                 \
struct SdfValueTypeTraits<SDF_VALUE_CPP_ARRAY_TYPE(elem)> {                 \
    static const bool IsValueType = true;                                   \
};

Definition at line 397 of file types.h.

◆ SDF_VALUE_ROLE_NAME_TOKENS

#define SDF_VALUE_ROLE_NAME_TOKENS

Value:

(Point)                                     \
    (Normal)                                    \
    (Vector)                                    \
    (Color)                                     \
    (Frame)                                     \
    (Transform)                                 \
    (PointIndex)                                \
    (EdgeIndex)                                 \
    (FaceIndex)                                 \
    (Group)                                     \
    (TextureCoordinate)

Definition at line 434 of file types.h.

Typedef Documentation

◆ SdfMapperParametersMap

typedef std::map<std::string, VtValue> SdfMapperParametersMap

A map of mapper parameter names to parameter values.

Definition at line 280 of file types.h.

◆ SdfRelocatesMap

typedef std::map<SdfPath, SdfPath> SdfRelocatesMap

A map of source SdfPaths to target SdfPaths for relocation.

Definition at line 292 of file types.h.

◆ SdfTimeSampleMap

typedef std::map<double, VtValue> SdfTimeSampleMap

A map from sample times to sample values.

Definition at line 295 of file types.h.

◆ SdfVariantSelectionMap

typedef std::map<std::string, std::string> SdfVariantSelectionMap

A map of reference variant set names to variants in those sets.

Definition at line 283 of file types.h.

◆ SdfVariantsMap

typedef std::map<std::string, std::vector<std::string> > SdfVariantsMap

A map of variant set names to list of variants in those sets.

Definition at line 286 of file types.h.

Enumeration Type Documentation

◆ SdfAuthoringError

enum SdfAuthoringError

An enum for TfError codes related to authoring operations.

SdfAuthoringError:

SdfAuthoringErrorUnrecognizedFields. This error is raised if SdfLayer::TransferContent, or SdfLayer::SetField API is called for layers of differing schema, and fields from the source layer are not recognized by the target layer's schema.
SdfAuthoringErrorUnrecognizedSpecType. This error is raised in attempts to create specs on layers with spec types that are not recognized by the layer's schema.

Definition at line 199 of file types.h.

◆ SdfPermission

enum SdfPermission

An enum that defines permission levels.

Permissions control which layers may refer to or express opinions about a prim. Opinions expressed about a prim, or relationships to that prim, by layers that are not allowed permission to access the prim will be ignored.

SdfPermission:

SdfPermissionPublic. Public prims can be referred to by anything. (Available to any client.)
SdfPermissionPrivate. Private prims can be referred to only within the local layer stack, and not across references or inherits. (Not available to clients.)
SdfNumPermission. Internal sentinel value.

Definition at line 154 of file types.h.

◆ SdfSpecifier

enum SdfSpecifier

An enum that identifies the possible specifiers for an SdfPrimSpec.

The SdfSpecifier enum is registered as a TfEnum for converting to and from std::string.

SdfSpecifier:

SdfSpecifierDef. Defines a concrete prim.
SdfSpecifierOver. Overrides an existing prim.
SdfSpecifierClass. Defines an abstract prim.
SdfNumSpecifiers. The number of specifiers.

Definition at line 122 of file types.h.

◆ SdfSpecType

enum SdfSpecType

An enum that specifies the type of an object.

Objects are entities that have fields and are addressable by path.

Definition at line 90 of file types.h.

◆ SdfVariability

enum SdfVariability

An enum that identifies variability types for attributes.

Variability indicates whether the attribute may vary over time and value coordinates, and if its value comes through authoring or or from its owner.

SdfVariability:

SdfVariabilityVarying. Varying attributes may be directly authored, animated and affected on by Actions. They are the most flexible.
SdfVariabilityUniform. Uniform attributes may be authored only with non-animated values (default values). They cannot be affected by Actions, but they can be connected to other Uniform attributes.
SdNumVariabilities. Internal sentinel value.

Definition at line 178 of file types.h.

Function Documentation

◆ operator<<() [1/4]

SDF_API std::ostream& operator<<	(	std::ostream &	out,
		const SdfSpecifier &	spec
	)

Writes the string representation of SdfSpecifier to out.

◆ operator<<() [2/4]

SDF_API std::ostream& operator<<	(	std::ostream &	out,
		const SdfRelocatesMap &	reloMap
	)

Writes the string representation of SdfRelocatesMap to out.

◆ operator<<() [3/4]

SDF_API std::ostream& operator<<	(	std::ostream &	out,
		const SdfTimeSampleMap &	sampleMap
	)

Writes the string representation of SdfTimeSampleMap to out.

◆ operator<<() [4/4]

SDF_API std::ostream& operator<<	(	std::ostream &	out,
		const SdfUnregisteredValue &	value
	)

Writes the string representation of SdfUnregisteredValue to out.

◆ SdfConvertToValidMetadataDictionary()

SDF_API bool SdfConvertToValidMetadataDictionary	(	VtDictionary *	dict,
		std::string *	errMsg
	)

Convert dict to a valid metadata dictionary for scene description.

Valid metadata dictionaries have values that are any of SDF_VALUE_TYPES (or VtArrays of those), plus VtDictionary with values of those types (or similarly nested VtDictionaries).

Certain conversions are performed in an attempt to produce a valid metadata dictionary. For example:

Convert std::vector<VtValue> to VtArray<T> where T is the type of the first element in the vector. Fail conversion for empty vectors where a concrete type cannot be inferred.

Convert python sequences to VtArray<T> where T is the type of the first element in the python sequence, when converted to VtValue, if that T is an SDF_VALUE_TYPE). Fail conversion for empty sequences where a concrete type cannot be inferred.

If any values cannot be converted to valid SDF_VALUE_TYPES, omit those elements and add a message to errMsg indicating which values were omitted.

◆ SdfConvertUnit()

SDF_API double SdfConvertUnit	(	const TfEnum &	fromUnit,
		const TfEnum &	toUnit
	)

Converts from one unit of measure to another.

The fromUnit and toUnit units must be of the same type (for example, both of type SdfLengthUnit).

◆ SdfDefaultUnit() [1/2]

SDF_API TfEnum SdfDefaultUnit ( TfToken const & typeName )

Gets the show default unit for the given /a typeName.

◆ SdfDefaultUnit() [2/2]

SDF_API const TfEnum& SdfDefaultUnit ( const TfEnum & unit )

Gets the show default unit for the given /a unit.

◆ SdfGetNameForUnit()

SDF_API const std::string& SdfGetNameForUnit ( const TfEnum & unit )

Gets the name for a given /a unit.

◆ SdfGetRoleNameForValueTypeName()

SDF_API TfToken SdfGetRoleNameForValueTypeName ( TfToken const & typeName )

Return role name for typeName.

Return empty token if typeName has no associated role name.

◆ SdfGetTypeForValueTypeName()

SDF_API TfType SdfGetTypeForValueTypeName ( TfToken const & name )

Given an sdf valueType name, produce TfType if the type name specifies a valid sdf value type.

◆ SdfGetUnitFromName()

SDF_API const TfEnum& SdfGetUnitFromName ( const std::string & name )

Gets a unit for the given /a name.

◆ SdfGetValueTypeNameForValue()

SDF_API SdfValueTypeName SdfGetValueTypeNameForValue ( VtValue const & value )

Given a value, produce the sdf valueType name.

If you provide a value that does not return true for SdfValueHasValidType, the return value is unspecified.

◆ SdfIsDefiningSpecifier()

bool SdfIsDefiningSpecifier ( SdfSpecifier spec )

inline

Returns true if the specifier defines a prim.

Definition at line 132 of file types.h.

◆ SdfUnitCategory()

SDF_API const std::string& SdfUnitCategory ( const TfEnum & unit )

Gets the unit category for a given /a unit.

◆ SdfValueHasValidType()

SDF_API bool SdfValueHasValidType ( VtValue const & value )

Given a value, returns if there is a valid corresponding valueType.

Classes

Macros

Typedefs

Enumerations

Functions

Variables

Detailed Description

Macro Definition Documentation

◆ _SDF_ANGULAR_UNITS

◆ _SDF_DECLARE_UNIT_ENUM

◆ _SDF_DIMENSIONED_VALUE_TYPES

◆ _SDF_DIMENSIONLESS_UNITS

◆ _SDF_LENGTH_UNITS

◆ _SDF_SCALAR_VALUE_TYPES

◆ _SDF_UNITS

◆ _SDF_UNITSLIST_ENUM

◆ SDF_DECLARE_VALUE_TYPE_TRAITS

◆ SDF_VALUE_ROLE_NAME_TOKENS

Typedef Documentation

◆ SdfMapperParametersMap

◆ SdfRelocatesMap

◆ SdfTimeSampleMap

◆ SdfVariantSelectionMap

◆ SdfVariantsMap

Enumeration Type Documentation

◆ SdfAuthoringError

◆ SdfPermission

◆ SdfSpecifier

◆ SdfSpecType

◆ SdfVariability

Function Documentation

◆ operator<<() [1/4]

◆ operator<<() [2/4]

◆ operator<<() [3/4]

◆ operator<<() [4/4]

◆ SdfConvertToValidMetadataDictionary()

◆ SdfConvertUnit()

◆ SdfDefaultUnit() [1/2]

◆ SdfDefaultUnit() [2/2]

◆ SdfGetNameForUnit()

◆ SdfGetRoleNameForValueTypeName()

◆ SdfGetTypeForValueTypeName()

◆ SdfGetUnitFromName()

◆ SdfGetValueTypeNameForValue()

◆ SdfIsDefiningSpecifier()

◆ SdfUnitCategory()

◆ SdfValueHasValidType()
