An abstract base class that knows how to sample a primvar signal given a ray hit coordinate: an <element, u, v> tuple. More...

Inheritance diagram for HdEmbreePrimvarSampler:

Public Member Functions
	HdEmbreePrimvarSampler ()=default
	Default constructor. More...

virtual	~HdEmbreePrimvarSampler ()=default
	Default destructor. More...

virtual bool	Sample (unsigned int element, float u, float v, void *value, HdTupleType dataType) const =0
	Sample the primvar at element index `index` and local basis coordinates `u` and `v`, writing the sample to `value`. More...

template<typename T >
bool	Sample (unsigned int element, float u, float v, T *value) const

Static Protected Member Functions
static bool	_Interpolate (void out, void samples, float weights, size_t sampleCount, HdTupleType dataType)
	Utility function for derived classes: combine multiple samples with blend weights: `out` = sum_i { `samples`[i] * `weights`[i] }. More...

Detailed Description

An abstract base class that knows how to sample a primvar signal given a ray hit coordinate: an <element, u, v> tuple.

It provides templated accessors, but derived classes are responsible for implementing appropriate sampling or interpolation modes.

Definition at line 135 of file sampler.h.

Constructor & Destructor Documentation

HdEmbreePrimvarSampler ( )

default

Default constructor.

virtual ~HdEmbreePrimvarSampler ( )

virtualdefault

Default destructor.

Member Function Documentation

static bool _Interpolate	(	void *	out,
		void **	samples,
		float *	weights,
		size_t	sampleCount,
		HdTupleType	dataType
	)

staticprotected

Utility function for derived classes: combine multiple samples with blend weights: out = sum_i { samples[i] * weights[i] }.

Parameters

out	The memory to write the output to (only written on success).
samples	The array of sample pointers (length `sampleCount`).
weights	The array of sample weights (length `sampleCount`).
sampleCount	The number of samples to combine.
dataType	The HdTupleType describing element values.

Returns: True if the samples were successfully combined.

virtual bool Sample	(	unsigned int	element,
		float	u,
		float	v,
		void *	value,
		HdTupleType	dataType
	)		const

pure virtual

Sample the primvar at element index index and local basis coordinates u and v, writing the sample to value.

Interpret value as having arity numComponents, each of type componentType. These parameters may not match the datatype declaration of the underlying buffer.

Derived classes are responsible for implementing sampling logic for their particular interpolation modes. Sample returns true if a value was successfully retrieved.

Parameters

element	The element index to sample.
u	The u coordinate to sample.
v	The v coordinate to sample.
value	The memory to write the value to (only written on success).
dataType	The HdTupleType describing element values.

Returns: True if the value was successfully sampled.

Implemented in HdEmbreeSubdivVertexSampler, HdEmbreeTriangleFaceVaryingSampler, HdEmbreeTriangleVertexSampler, HdEmbreeUniformSampler, and HdEmbreeConstantSampler.

The documentation for this class was generated from the following file:

pxr/imaging/hdEmbree/sampler.h
