Hydra Schema for a subdivision surface or poly-mesh object. More...

Inheritance diagram for HdMesh:

Public Member Functions
bool	IsDoubleSided (HdSceneDelegate *delegate) const
	Render State. More...

HdCullStyle	GetCullStyle (HdSceneDelegate *delegate) const

VtValue	GetShadingStyle (HdSceneDelegate *delegate) const

HdMeshTopology	GetMeshTopology (HdSceneDelegate *delegate) const
	Topological accessors via the scene delegate. More...

HdDisplayStyle	GetDisplayStyle (HdSceneDelegate *delegate) const

PxOsdSubdivTags	GetSubdivTags (HdSceneDelegate *delegate) const

virtual HdMeshTopologySharedPtr	GetTopology () const
	Topology getter. More...

VtValue	GetPoints (HdSceneDelegate *delegate) const
	Primvars Accessors. More...

VtValue	GetNormals (HdSceneDelegate *delegate) const

HD_API TfTokenVector const &	GetBuiltinPrimvarNames () const override
	Returns the names of built-in primvars, i.e. More...

Public Member Functions inherited from HdRprim
HD_API	HdRprim (SdfPath const &id)

HD_API const HdRepr::DrawItemUniquePtrVector &	GetDrawItems (TfToken const &reprToken) const
	Returns the draw items for the requested repr token, if any. More...

virtual HD_API void	Finalize (HdRenderParam *renderParam)
	Finalizes object resources. More...

SdfPath const &	GetId () const
	Returns the identifier of this Rprim. More...

int32_t	GetPrimId () const
	Return the unique instance id. More...

HD_API void	SetPrimId (int32_t primId)
	Set the unique instance id. More...

SdfPath const &	GetInstancerId () const
	Returns the identifier of the instancer (if any) for this Rprim. More...

SdfPath const &	GetMaterialId () const
	Returns the path of the material to which this Rprim is bound. More...

HD_API void	SetMaterialId (SdfPath const &materialId)
	Sets a new material binding to be used by this rprim. More...

TfToken const &	GetMaterialTag () const
	The MaterialTag allows rprims to be organized into different collections based on properties of the prim's material. More...

HD_API void	SetMaterialTag (TfToken const &materialTag)
	Sets the material tag used by the rprim. More...

HdReprSelector const &	GetReprSelector () const

TfToken	GetRenderTag (HdSceneDelegate *delegate) const
	Returns the render tag associated to this rprim. More...

GfRange3d	GetExtent (HdSceneDelegate *delegate) const
	Returns the bounds of the rprim in local, untransformed space. More...

HdPrimvarDescriptorVector	GetPrimvarDescriptors (HdSceneDelegate *delegate, HdInterpolation interpolation) const
	Primvar Query. More...

VtValue	GetPrimvar (HdSceneDelegate *delegate, const TfToken &name) const

VtValue	GetIndexedPrimvar (HdSceneDelegate delegate, const TfToken &name, VtIntArray indices) const

HD_API VtMatrix4dArray	GetInstancerTransforms (HdSceneDelegate *delegate)

HD_API bool	IsDirty (HdChangeTracker &changeTracker) const
	Returns true if any dirty flags are set for this rprim. More...

bool	IsVisible () const
	Is the prim itself visible. More...

HD_API void	UpdateReprSelector (HdSceneDelegate delegate, HdDirtyBits dirtyBits)

virtual HdDirtyBits	GetInitialDirtyBitsMask () const =0
	Returns the set of dirty bits that should be added to the change tracker for this prim, when this prim is inserted. More...

HD_API bool	CanSkipDirtyBitPropagationAndSync (HdDirtyBits bits) const
	This function gives an Rprim the chance to "early exit" from dirty bit propagation, delegate sync and rprim sync altogether. More...

HD_API HdDirtyBits	PropagateRprimDirtyBits (HdDirtyBits bits)
	This function gives an Rprim the chance to set additional dirty bits based on those set in the change tracker, before passing the dirty bits to the scene delegate. More...

HD_API void	InitRepr (HdSceneDelegate delegate, TfToken const &reprToken, HdDirtyBits dirtyBits)
	Initialize the representation of this Rprim by calling _InitRepr. More...

virtual void	Sync (HdSceneDelegate delegate, HdRenderParam renderParam, HdDirtyBits *dirtyBits, TfToken const &reprToken)=0
	Pull invalidated scene data and prepare/update the renderable representation. More...

Static Public Member Functions
static HD_API void	ConfigureRepr (TfToken const &reprName, HdMeshReprDesc desc1, HdMeshReprDesc desc2=HdMeshReprDesc())
	Configure the geometric style of the mesh for a given representation. More...

Protected Types
typedef _ReprDescConfigs < HdMeshReprDesc, 2 >	_MeshReprConfig

Protected Types inherited from HdRprim
typedef std::vector< std::pair < TfToken, HdReprSharedPtr > >	_ReprVector

Protected Member Functions
HD_API	HdMesh (SdfPath const &id)
	Constructor. More...

Protected Member Functions inherited from HdRprim
HD_API HdReprSharedPtr const &	_GetRepr (TfToken const &reprToken) const

HD_API void	_UpdateVisibility (HdSceneDelegate sceneDelegate, HdDirtyBits dirtyBits)

HD_API void	_UpdateInstancer (HdSceneDelegate sceneDelegate, HdDirtyBits dirtyBits)

virtual HdDirtyBits	_PropagateDirtyBits (HdDirtyBits bits) const =0
	This callback from Rprim gives the prim an opportunity to set additional dirty bits based on those already set. More...

virtual void	_InitRepr (TfToken const &reprToken, HdDirtyBits *dirtyBits)=0
	Initialize the given representation of this Rprim. More...

Static Protected Member Functions
static HD_API _MeshReprConfig::DescArray	_GetReprDesc (TfToken const &reprName)

Detailed Description

Hydra Schema for a subdivision surface or poly-mesh object.

Definition at line 105 of file mesh.h.

Constructor & Destructor Documentation

HD_API HdMesh ( SdfPath const & id )

protected

Constructor.

instancerId, if specified, is the instancer which uses this mesh as a prototype.

Member Function Documentation

static HD_API void ConfigureRepr	(	TfToken const &	reprName,
		HdMeshReprDesc	desc1,
		HdMeshReprDesc	desc2 = `HdMeshReprDesc()`
	)

static

Configure the geometric style of the mesh for a given representation.

We currently allow up to 2 descriptors for a representation. Example of when this may be useful: Drawing the outline in addition to the surface for a mesh.

HD_API TfTokenVector const& GetBuiltinPrimvarNames ( ) const

overridevirtual

Returns the names of built-in primvars, i.e.

primvars that are part of the core geometric schema for this prim.

Implements HdRprim.

HdMeshTopology GetMeshTopology ( HdSceneDelegate * delegate ) const

inline

Topological accessors via the scene delegate.

Definition at line 186 of file mesh.h.

VtValue GetPoints ( HdSceneDelegate * delegate ) const

inline

Primvars Accessors.

Definition at line 210 of file mesh.h.

HdMeshTopologySharedPtr GetTopology ( ) const

inlinevirtual

Topology getter.

Reimplemented in HdStMesh.

Definition at line 204 of file mesh.h.

bool IsDoubleSided ( HdSceneDelegate * delegate ) const

inline

Render State.

Definition at line 168 of file mesh.h.

The documentation for this class was generated from the following file:

pxr/imaging/hd/mesh.h
