Hydra Schema for a point cloud. More...
Inheritance diagram for HdPoints:Public Member Functions | |
| HD_API TfTokenVector const & | GetBuiltinPrimvarNames () const override |
| Returns the names of built-in primvars, i.e. More... | |
| Public Member Functions inherited from HdRprim | |
| HD_API | HdRprim (SdfPath const &id) |
| HD_API const HdRepr::DrawItemUniquePtrVector & | GetDrawItems (TfToken const &reprToken) const |
| Returns the draw items for the requested repr token, if any. More... | |
| virtual HD_API void | Finalize (HdRenderParam *renderParam) |
| Finalizes object resources. More... | |
| SdfPath const & | GetId () const |
| Returns the identifier of this Rprim. More... | |
| int32_t | GetPrimId () const |
| Return the unique instance id. More... | |
| HD_API void | SetPrimId (int32_t primId) |
| Set the unique instance id. More... | |
| SdfPath const & | GetInstancerId () const |
| Returns the identifier of the instancer (if any) for this Rprim. More... | |
| SdfPath const & | GetMaterialId () const |
| Returns the path of the material to which this Rprim is bound. More... | |
| HD_API void | SetMaterialId (SdfPath const &materialId) |
| Sets a new material binding to be used by this rprim. More... | |
| TfToken const & | GetMaterialTag () const |
| The MaterialTag allows rprims to be organized into different collections based on properties of the prim's material. More... | |
| HD_API void | SetMaterialTag (TfToken const &materialTag) |
| Sets the material tag used by the rprim. More... | |
| HdReprSelector const & | GetReprSelector () const |
| TfToken | GetRenderTag (HdSceneDelegate *delegate) const |
| Returns the render tag associated to this rprim. More... | |
| GfRange3d | GetExtent (HdSceneDelegate *delegate) const |
| Returns the bounds of the rprim in local, untransformed space. More... | |
| HdPrimvarDescriptorVector | GetPrimvarDescriptors (HdSceneDelegate *delegate, HdInterpolation interpolation) const |
| Primvar Query. More... | |
| VtValue | GetPrimvar (HdSceneDelegate *delegate, const TfToken &name) const |
| VtValue | GetIndexedPrimvar (HdSceneDelegate *delegate, const TfToken &name, VtIntArray *indices) const |
| HD_API VtMatrix4dArray | GetInstancerTransforms (HdSceneDelegate *delegate) |
| HD_API bool | IsDirty (HdChangeTracker &changeTracker) const |
| Returns true if any dirty flags are set for this rprim. More... | |
| bool | IsVisible () const |
| Is the prim itself visible. More... | |
| HD_API void | UpdateReprSelector (HdSceneDelegate *delegate, HdDirtyBits *dirtyBits) |
| virtual HdDirtyBits | GetInitialDirtyBitsMask () const =0 |
| Returns the set of dirty bits that should be added to the change tracker for this prim, when this prim is inserted. More... | |
| HD_API bool | CanSkipDirtyBitPropagationAndSync (HdDirtyBits bits) const |
| This function gives an Rprim the chance to "early exit" from dirty bit propagation, delegate sync and rprim sync altogether. More... | |
| HD_API HdDirtyBits | PropagateRprimDirtyBits (HdDirtyBits bits) |
| This function gives an Rprim the chance to set additional dirty bits based on those set in the change tracker, before passing the dirty bits to the scene delegate. More... | |
| HD_API void | InitRepr (HdSceneDelegate *delegate, TfToken const &reprToken, HdDirtyBits *dirtyBits) |
| Initialize the representation of this Rprim by calling _InitRepr. More... | |
| virtual void | Sync (HdSceneDelegate *delegate, HdRenderParam *renderParam, HdDirtyBits *dirtyBits, TfToken const &reprToken)=0 |
| Pull invalidated scene data and prepare/update the renderable representation. More... | |
Static Public Member Functions | |
| static HD_API void | ConfigureRepr (TfToken const &reprName, const HdPointsReprDesc &desc) |
Configure geometric style of drawItems for reprName. More... | |
Protected Types | |
|
typedef _ReprDescConfigs < HdPointsReprDesc > | _PointsReprConfig |
| Protected Types inherited from HdRprim | |
|
typedef std::vector< std::pair < TfToken, HdReprSharedPtr > > | _ReprVector |
Protected Member Functions | |
| HD_API | HdPoints (SdfPath const &id) |
| Constructor. More... | |
| Protected Member Functions inherited from HdRprim | |
| HD_API HdReprSharedPtr const & | _GetRepr (TfToken const &reprToken) const |
| HD_API void | _UpdateVisibility (HdSceneDelegate *sceneDelegate, HdDirtyBits *dirtyBits) |
| HD_API void | _UpdateInstancer (HdSceneDelegate *sceneDelegate, HdDirtyBits *dirtyBits) |
| virtual HdDirtyBits | _PropagateDirtyBits (HdDirtyBits bits) const =0 |
| This callback from Rprim gives the prim an opportunity to set additional dirty bits based on those already set. More... | |
| virtual void | _InitRepr (TfToken const &reprToken, HdDirtyBits *dirtyBits)=0 |
| Initialize the given representation of this Rprim. More... | |
Static Protected Member Functions | |
|
static HD_API _PointsReprConfig::DescArray | _GetReprDesc (TfToken const &reprName) |
Constructor.
instancerId, if specified, is the instancer which uses this point cloud as a prototype.
|
static |
Configure geometric style of drawItems for reprName.
|
overridevirtual |
Returns the names of built-in primvars, i.e.
primvars that are part of the core geometric schema for this prim.
Implements HdRprim.
