A task for rendering geometry to pixels. More...

Inheritance diagram for HdxRenderTask:

Public Member Functions
HDX_API	HdxRenderTask (HdSceneDelegate *delegate, SdfPath const &id)

HDX_API bool	IsConverged () const override
	Hooks for progressive rendering (delegated to renderpasses). More...

HDX_API void	Prepare (HdTaskContext ctx, HdRenderIndex renderIndex) override
	Prepare the tasks resources. More...

HDX_API void	Execute (HdTaskContext *ctx) override
	Execute render pass task. More...

HDX_API const TfTokenVector &	GetRenderTags () const override
	Collect Render Tags used by the task. More...

Public Member Functions inherited from HdxTask
HDX_API	HdxTask (SdfPath const &id)

void	Sync (HdSceneDelegate delegate, HdTaskContext ctx, HdDirtyBits *dirtyBits) final
	We override HdTask::Sync, but make it 'final' to make sure derived classes can't override it and instead override _Sync. More...

Public Member Functions inherited from HdTask
HD_API	HdTask (SdfPath const &id)
	Construct a new task. More...

virtual void	Sync (HdSceneDelegate delegate, HdTaskContext ctx, HdDirtyBits *dirtyBits)=0
	Sync Phase: Obtain task state from Scene delegate based on change processing. More...

virtual void	Prepare (HdTaskContext ctx, HdRenderIndex renderIndex)=0
	Prepare Phase: Resolve bindings and manage resources. More...

virtual void	Execute (HdTaskContext *ctx)=0
	Execute Phase: Runs the task. More...

virtual HD_API const TfTokenVector &	GetRenderTags () const
	Render Tag Gather. More...

SdfPath const &	GetId () const

virtual HD_API HdDirtyBits	GetInitialDirtyBitsMask () const
	Returns the minimal set of dirty bits to place in the change tracker for use in the first sync of this prim. More...

Protected Member Functions
HDX_API void	_Sync (HdSceneDelegate delegate, HdTaskContext ctx, HdDirtyBits *dirtyBits) override
	Sync the render pass resources. More...

HDX_API HdRenderPassStateSharedPtr	_GetRenderPassState (HdTaskContext *ctx) const

HDX_API bool	_HasDrawItems () const

Protected Member Functions inherited from HdxTask
void	_ToggleRenderTarget (HdTaskContext *ctx)

HDX_API Hgi *	_GetHgi () const

Protected Member Functions inherited from HdTask
template<class T >
bool	_GetTaskParams (HdSceneDelegate delegate, T outValue)
	Extracts a typed value out of the task context at the given id. More...

HD_API TfTokenVector	_GetTaskRenderTags (HdSceneDelegate *delegate)

Additional Inherited Members
Static Protected Member Functions inherited from HdTask
static HD_API bool	_HasTaskContextData (HdTaskContext const *ctx, TfToken const &id)
	Check if the shared context contains a value for the given id. More...

template<class T >
static bool	_GetTaskContextData (HdTaskContext const ctx, TfToken const &id, T outValue)
	Extracts a typed value out of the task context at the given id. More...

template<class T >
static T	_GetDriver (HdTaskContext const *ctx, TfToken const &driverName)
	Extract an object from a HdDriver inside the task context. More...

Protected Attributes inherited from HdxTask
Hgi *	_hgi

Detailed Description

A task for rendering geometry to pixels.

Rendering state management can be handled two ways: 1.) An application can create an HdxRenderTask and pass it the HdxRenderTaskParams struct as "params". 2.) An application can create an HdxRenderSetupTask and an HdxRenderTask, and pass params to the setup task. In this case the setup task must run first.

Parameter unpacking is handled by HdxRenderSetupTask; in case #1, HdxRenderTask creates a dummy setup task internally to manage the sync process.

Case #2 introduces complexity; the benefit is that by changing which setup task you run before the render task, you can change the render parameters without incurring a hydra sync or rebuilding any resources.

Definition at line 64 of file renderTask.h.

Member Function Documentation

HDX_API void _Sync	(	HdSceneDelegate *	delegate,
		HdTaskContext *	ctx,
		HdDirtyBits *	dirtyBits
	)

overrideprotectedvirtual

Sync the render pass resources.

Implements HdxTask.

HDX_API void Execute ( HdTaskContext * ctx )

override

Execute render pass task.

HDX_API const TfTokenVector& GetRenderTags ( ) const

override

Collect Render Tags used by the task.

HDX_API bool IsConverged ( ) const

overridevirtual

Hooks for progressive rendering (delegated to renderpasses).

Reimplemented from HdxTask.

HDX_API void Prepare	(	HdTaskContext *	ctx,
		HdRenderIndex *	renderIndex
	)

override

Prepare the tasks resources.

The documentation for this class was generated from the following file:

pxr/imaging/hdx/renderTask.h
