Base class for field primitives. More...

Inheritance diagram for UsdVolFieldBase:

Public Member Functions
	UsdVolFieldBase (const UsdPrim &prim=UsdPrim())
	Construct a UsdVolFieldBase on UsdPrim `prim` . More...

	UsdVolFieldBase (const UsdSchemaBase &schemaObj)
	Construct a UsdVolFieldBase on the prim held by `schemaObj` . More...

virtual USDVOL_API	~UsdVolFieldBase ()
	Destructor. More...

Public Member Functions inherited from UsdGeomBoundable
	UsdGeomBoundable (const UsdPrim &prim=UsdPrim())
	Construct a UsdGeomBoundable on UsdPrim `prim` . More...

	UsdGeomBoundable (const UsdSchemaBase &schemaObj)
	Construct a UsdGeomBoundable on the prim held by `schemaObj` . More...

virtual USDGEOM_API	~UsdGeomBoundable ()
	Destructor. More...

USDGEOM_API UsdAttribute	GetExtentAttr () const
	Extent is a three dimensional range measuring the geometric extent of the authored gprim in its own local space (i.e. More...

USDGEOM_API UsdAttribute	CreateExtentAttr (VtValue const &defaultValue=VtValue(), bool writeSparsely=false) const
	See GetExtentAttr(), and also Create vs Get Property Methods for when to use Get vs Create. More...

Public Member Functions inherited from UsdGeomXformable
	UsdGeomXformable (const UsdPrim &prim=UsdPrim())
	Construct a UsdGeomXformable on UsdPrim `prim` . More...

	UsdGeomXformable (const UsdSchemaBase &schemaObj)
	Construct a UsdGeomXformable on the prim held by `schemaObj` . More...

virtual USDGEOM_API	~UsdGeomXformable ()
	Destructor. More...

USDGEOM_API UsdAttribute	GetXformOpOrderAttr () const
	Encodes the sequence of transformation operations in the order in which they should be pushed onto a transform stack while visiting a UsdStage's prims in a graph traversal that will effect the desired positioning for this prim and its descendant prims. More...

USDGEOM_API UsdAttribute	CreateXformOpOrderAttr (VtValue const &defaultValue=VtValue(), bool writeSparsely=false) const
	See GetXformOpOrderAttr(), and also Create vs Get Property Methods for when to use Get vs Create. More...

USDGEOM_API UsdGeomXformOp	AddXformOp (UsdGeomXformOp::Type const opType, UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionDouble, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add an affine transformation to the local stack represented by this Xformable. More...

USDGEOM_API UsdGeomXformOp	AddTranslateOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionDouble, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a translate operation to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddScaleOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a scale operation to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateXOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation about the X-axis to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateYOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation about the YX-axis to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateZOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation about the Z-axis to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateXYZOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with XYZ rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateXZYOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with XZY rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateYXZOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with YXZ rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateYZXOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with YZX rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateZXYOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with ZXY rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddRotateZYXOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a rotation op with ZYX rotation order to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddOrientOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionFloat, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a orient op (arbitrary axis/angle rotation) to the local stack represented by this xformable. More...

USDGEOM_API UsdGeomXformOp	AddTransformOp (UsdGeomXformOp::Precision const precision=UsdGeomXformOp::PrecisionDouble, TfToken const &opSuffix=TfToken(), bool isInverseOp=false) const
	Add a tranform op (4x4 matrix transformation) to the local stack represented by this xformable. More...

USDGEOM_API bool	SetResetXformStack (bool resetXform) const
	Specify whether this prim's transform should reset the transformation stack inherited from its parent prim. More...

USDGEOM_API bool	GetResetXformStack () const
	Does this prim reset its parent's inherited transformation? More...

USDGEOM_API bool	SetXformOpOrder (std::vector< UsdGeomXformOp > const &orderedXformOps, bool resetXformStack=false) const
	Reorder the already-existing transform ops on this prim. More...

USDGEOM_API std::vector < UsdGeomXformOp >	GetOrderedXformOps (bool *resetsXformStack) const
	Return the ordered list of transform operations to be applied to this prim, in least-to-most-local order. More...

USDGEOM_API bool	ClearXformOpOrder () const
	Clears the local transform stack. More...

USDGEOM_API UsdGeomXformOp	MakeMatrixXform () const
	Clears the existing local transform stack and creates a new xform op of type 'transform'. More...

USDGEOM_API bool	TransformMightBeTimeVarying () const
	Determine whether there is any possibility that this prim's local transformation may vary over time. More...

USDGEOM_API bool	TransformMightBeTimeVarying (const std::vector< UsdGeomXformOp > &ops) const
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Determine whether there is any possibility that this prim's local transformation may vary over time, using a pre-fetched (cached) list of ordered xform ops supplied by the client. More...

USDGEOM_API bool	GetTimeSamples (std::vector< double > *times) const
	Sets `times` to the union of all the timesamples at which xformOps that are included in the xformOpOrder attribute are authored. More...

USDGEOM_API bool	GetTimeSamplesInInterval (const GfInterval &interval, std::vector< double > *times) const
	Sets `times` to the union of all the timesamples in the interval, `interval`, at which xformOps that are included in the xformOpOrder attribute are authored. More...

USDGEOM_API bool	GetLocalTransformation (GfMatrix4d transform, bool resetsXformStack, const UsdTimeCode time=UsdTimeCode::Default()) const
	Computes the fully-combined, local-to-parent transformation for this prim. More...

USDGEOM_API bool	GetLocalTransformation (GfMatrix4d transform, bool resetsXformStack, const std::vector< UsdGeomXformOp > &ops, const UsdTimeCode time=UsdTimeCode::Default()) const
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Computes the fully-combined, local-to-parent transformation for this prim as efficiently as possible, using a pre-fetched (cached) list of ordered xform ops supplied by the client. More...

Public Member Functions inherited from UsdGeomImageable
	UsdGeomImageable (const UsdPrim &prim=UsdPrim())
	Construct a UsdGeomImageable on UsdPrim `prim` . More...

	UsdGeomImageable (const UsdSchemaBase &schemaObj)
	Construct a UsdGeomImageable on the prim held by `schemaObj` . More...

virtual USDGEOM_API	~UsdGeomImageable ()
	Destructor. More...

USDGEOM_API UsdAttribute	GetVisibilityAttr () const
	Visibility is meant to be the simplest form of "pruning" visibility that is supported by most DCC apps. More...

USDGEOM_API UsdAttribute	CreateVisibilityAttr (VtValue const &defaultValue=VtValue(), bool writeSparsely=false) const
	See GetVisibilityAttr(), and also Create vs Get Property Methods for when to use Get vs Create. More...

USDGEOM_API UsdAttribute	GetPurposeAttr () const
	Purpose is a classification of geometry into categories that can each be independently included or excluded from traversals of prims on a stage, such as rendering or bounding-box computation traversals. More...

USDGEOM_API UsdAttribute	CreatePurposeAttr (VtValue const &defaultValue=VtValue(), bool writeSparsely=false) const
	See GetPurposeAttr(), and also Create vs Get Property Methods for when to use Get vs Create. More...

USDGEOM_API UsdRelationship	GetProxyPrimRel () const
	The proxyPrim relationship allows us to link a prim whose purpose is "render" to its (single target) purpose="proxy" prim. More...

USDGEOM_API UsdRelationship	CreateProxyPrimRel () const
	See GetProxyPrimRel(), and also Create vs Get Property Methods for when to use Get vs Create. More...

USDGEOM_API void	MakeVisible (const UsdTimeCode &time=UsdTimeCode::Default()) const
	Make the imageable visible if it is invisible at the given time. More...

USDGEOM_API void	MakeInvisible (const UsdTimeCode &time=UsdTimeCode::Default()) const
	Makes the imageable invisible if it is visible at the given time. More...

USDGEOM_API TfToken	ComputeVisibility (UsdTimeCode const &time=UsdTimeCode::Default()) const
	Calculate the effective visibility of this prim, as defined by its most ancestral authored "invisible" opinion, if any. More...

USDGEOM_API TfToken	ComputeVisibility (const TfToken &parentVisibility, UsdTimeCode const &time=UsdTimeCode::Default()) const
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Calculates the effective visibility of this prim, given the computed visibility of its parent prim at the given `time`. More...

USDGEOM_API PurposeInfo	ComputePurposeInfo () const
	Calculate the effective purpose information about this prim which includes final computed purpose value of the prim as well as whether the purpose value should be inherited by namespace children without their own purpose opinions. More...

USDGEOM_API PurposeInfo	ComputePurposeInfo (const PurposeInfo &parentPurposeInfo) const
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Calculates the effective purpose information about this prim, given the computed purpose information of its parent prim. More...

USDGEOM_API TfToken	ComputePurpose () const
	Calculate the effective purpose information about this prim. More...

USDGEOM_API UsdPrim	ComputeProxyPrim (UsdPrim *renderPrim=NULL) const
	Find the prim whose purpose is proxy that serves as the proxy for this prim, as established by the GetProxyPrimRel(), or an invalid UsdPrim if this prim has no proxy. More...

USDGEOM_API bool	SetProxyPrim (const UsdPrim &proxy) const
	Convenience function for authoring the renderProxy rel on this prim to target the given `proxy` prim. More...

USDGEOM_API bool	SetProxyPrim (const UsdSchemaBase &proxy) const

USDGEOM_API GfBBox3d	ComputeWorldBound (UsdTimeCode const &time, TfToken const &purpose1=TfToken(), TfToken const &purpose2=TfToken(), TfToken const &purpose3=TfToken(), TfToken const &purpose4=TfToken()) const
	Compute the bound of this prim in world space, at the specified `time`, and for the specified purposes. More...

USDGEOM_API GfBBox3d	ComputeLocalBound (UsdTimeCode const &time, TfToken const &purpose1=TfToken(), TfToken const &purpose2=TfToken(), TfToken const &purpose3=TfToken(), TfToken const &purpose4=TfToken()) const
	Compute the bound of this prim in local space, at the specified `time`, and for the specified purposes. More...

USDGEOM_API GfBBox3d	ComputeUntransformedBound (UsdTimeCode const &time, TfToken const &purpose1=TfToken(), TfToken const &purpose2=TfToken(), TfToken const &purpose3=TfToken(), TfToken const &purpose4=TfToken()) const
	Compute the untransformed bound of this prim, at the specified `time`, and for the specified purposes. More...

USDGEOM_API GfMatrix4d	ComputeLocalToWorldTransform (UsdTimeCode const &time) const
	Compute the transformation matrix for this prim at the given time, including the transform authored on the Prim itself, if present. More...

USDGEOM_API GfMatrix4d	ComputeParentToWorldTransform (UsdTimeCode const &time) const
	Compute the transformation matrix for this prim at the given time, NOT including the transform authored on the prim itself. More...

USDGEOM_API UsdGeomPrimvar	CreatePrimvar (const TfToken &attrName, const SdfValueTypeName &typeName, const TfToken &interpolation=TfToken(), int elementSize=-1) const

USDGEOM_API UsdGeomPrimvar	GetPrimvar (const TfToken &name) const

USDGEOM_API std::vector < UsdGeomPrimvar >	GetPrimvars () const

USDGEOM_API std::vector < UsdGeomPrimvar >	GetAuthoredPrimvars () const

USDGEOM_API bool	HasPrimvar (const TfToken &name) const

Public Member Functions inherited from UsdTyped
	UsdTyped (const UsdPrim &prim=UsdPrim())
	Construct a UsdTyped on UsdPrim `prim` . More...

	UsdTyped (const UsdSchemaBase &schemaObj)
	Construct a UsdTyped on the prim wrapped by `schemaObj` . More...

Public Member Functions inherited from UsdSchemaBase
bool	IsConcrete () const
	Returns whether or not this class corresponds to a concrete instantiable prim type in scene description. More...

bool	IsTyped () const
	Returns whether or not this class inherits from UsdTyped. More...

bool	IsAPISchema () const
	Returns whether this is an API schema or not. More...

bool	IsAppliedAPISchema () const
	Returns whether this is an applied API schema or not. More...

bool	IsMultipleApplyAPISchema () const
	Returns whether this is an applied API schema or not. More...

UsdSchemaKind	GetSchemaKind () const
	Returns the kind of schema this class is. More...

USD_API	UsdSchemaBase (const UsdPrim &prim=UsdPrim())
	Construct and store `prim` as the held prim. More...

USD_API	UsdSchemaBase (const UsdSchemaBase &otherSchema)
	Construct and store for the same prim held by `otherSchema`. More...

virtual USD_API	~UsdSchemaBase ()
	Destructor. More...

USD_API	operator bool () const

UsdPrim	GetPrim () const
	Return this schema object's held prim. More...

SdfPath	GetPath () const
	Shorthand for GetPrim()->GetPath(). More...

USD_API const UsdPrimDefinition *	GetSchemaClassPrimDefinition () const
	Return the prim definition associated with this schema instance if one exists, otherwise return null. More...

Static Public Member Functions
static USDVOL_API const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)
	Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes. More...

static USDVOL_API UsdVolFieldBase	Get (const UsdStagePtr &stage, const SdfPath &path)
	Return a UsdVolFieldBase holding the prim adhering to this schema at `path` on `stage`. More...

Static Public Member Functions inherited from UsdGeomBoundable
static USDGEOM_API const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)
	Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes. More...

static USDGEOM_API UsdGeomBoundable	Get (const UsdStagePtr &stage, const SdfPath &path)
	Return a UsdGeomBoundable holding the prim adhering to this schema at `path` on `stage`. More...

static USDGEOM_API bool	ComputeExtentFromPlugins (const UsdGeomBoundable &boundable, const UsdTimeCode &time, VtVec3fArray *extent)
	Compute the extent for the Boundable prim `boundable` at time `time`. More...

static USDGEOM_API bool	ComputeExtentFromPlugins (const UsdGeomBoundable &boundable, const UsdTimeCode &time, const GfMatrix4d &transform, VtVec3fArray *extent)
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. Computes the extent as if the matrix `transform` was first applied. More...

Static Public Member Functions inherited from UsdGeomXformable
static USDGEOM_API const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)
	Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes. More...

static USDGEOM_API UsdGeomXformable	Get (const UsdStagePtr &stage, const SdfPath &path)
	Return a UsdGeomXformable holding the prim adhering to this schema at `path` on `stage`. More...

static USDGEOM_API bool	GetTimeSamples (std::vector< UsdGeomXformOp > const &orderedXformOps, std::vector< double > *times)
	Returns the union of all the timesamples at which the attributes belonging to the given `orderedXformOps` are authored. More...

static USDGEOM_API bool	GetTimeSamplesInInterval (std::vector< UsdGeomXformOp > const &orderedXformOps, const GfInterval &interval, std::vector< double > *times)
	Returns the union of all the timesamples in the `interval` at which the attributes belonging to the given `orderedXformOps` are authored. More...

static USDGEOM_API bool	GetLocalTransformation (GfMatrix4d *transform, std::vector< UsdGeomXformOp > const &ops, const UsdTimeCode time)
	This is an overloaded member function, provided for convenience. It differs from the above function only in what argument(s) it accepts. This is a static version of the preceding function that takes a cached list of ordered xform ops. More...

static USDGEOM_API bool	IsTransformationAffectedByAttrNamed (const TfToken &attrName)
	Returns true if the attribute named `attrName` could affect the local transformation of an xformable prim. More...

Static Public Member Functions inherited from UsdGeomImageable
static USDGEOM_API const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)
	Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes. More...

static USDGEOM_API UsdGeomImageable	Get (const UsdStagePtr &stage, const SdfPath &path)
	Return a UsdGeomImageable holding the prim adhering to this schema at `path` on `stage`. More...

static USDGEOM_API const TfTokenVector &	GetOrderedPurposeTokens ()
	Returns an ordered list of allowed values of the purpose attribute. More...

Static Public Member Functions inherited from UsdTyped
static const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)
	Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes. More...

static USD_API UsdTyped	Get (const UsdStagePtr &stage, const SdfPath &path)
	Return a UsdTyped holding the prim adhering to this schema at `path` on `stage`. More...

Static Public Member Functions inherited from UsdSchemaBase
static const TfTokenVector &	GetSchemaAttributeNames (bool includeInherited=true)

Static Public Attributes
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractTyped
	Compile time constant representing what kind of schema this class is. More...

Static Public Attributes inherited from UsdGeomBoundable
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractTyped
	Compile time constant representing what kind of schema this class is. More...

Static Public Attributes inherited from UsdGeomXformable
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractTyped
	Compile time constant representing what kind of schema this class is. More...

Static Public Attributes inherited from UsdGeomImageable
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractTyped
	Compile time constant representing what kind of schema this class is. More...

Static Public Attributes inherited from UsdTyped
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractBase
	Compile time constant representing what kind of schema this class is. More...

Static Public Attributes inherited from UsdSchemaBase
static const UsdSchemaKind	schemaKind = UsdSchemaKind::AbstractBase
	Compile time constant representing what kind of schema this class is. More...

Protected Member Functions
USDVOL_API UsdSchemaKind	_GetSchemaKind () const override
	Returns the kind of schema this class belongs to. More...

Protected Member Functions inherited from UsdTyped
USD_API bool	_IsCompatible () const override
	Subclasses may override _IsCompatible to do specific compatibility checking with the given prim, such as type compatibility or value compatibility. More...

Protected Member Functions inherited from UsdSchemaBase
virtual UsdSchemaKind	_GetSchemaType () const

const TfType &	_GetType () const

USD_API UsdAttribute	_CreateAttr (TfToken const &attrName, SdfValueTypeName const &typeName, bool custom, SdfVariability variability, VtValue const &defaultValue, bool writeSparsely) const

Friends
class	UsdSchemaRegistry

Detailed Description

Base class for field primitives.

Definition at line 56 of file fieldBase.h.

Constructor & Destructor Documentation

UsdVolFieldBase ( const UsdPrim & prim = UsdPrim() )

inlineexplicit

Construct a UsdVolFieldBase on UsdPrim prim .

Equivalent to UsdVolFieldBase::Get(prim.GetStage(), prim.GetPath()) for a valid prim, but will not immediately throw an error for an invalid prim

Definition at line 68 of file fieldBase.h.

UsdVolFieldBase ( const UsdSchemaBase & schemaObj )

inlineexplicit

Construct a UsdVolFieldBase on the prim held by schemaObj .

Should be preferred over UsdVolFieldBase(schemaObj.GetPrim()), as it preserves SchemaBase state.

Definition at line 76 of file fieldBase.h.

virtual USDVOL_API ~UsdVolFieldBase ( )

virtual

Destructor.

Member Function Documentation

USDVOL_API UsdSchemaKind _GetSchemaKind ( ) const

overrideprotectedvirtual

Returns the kind of schema this class belongs to.

See Also: UsdSchemaKind

Reimplemented from UsdGeomBoundable.

Reimplemented in UsdVolOpenVDBAsset.

static USDVOL_API UsdVolFieldBase Get	(	const UsdStagePtr &	stage,
		const SdfPath &	path
	)

static

Return a UsdVolFieldBase holding the prim adhering to this schema at path on stage.

If no prim exists at path on stage, or if the prim at that path does not adhere to this schema, return an invalid schema object. This is shorthand for the following:

* UsdVolFieldBase(stage->GetPrimAtPath(path));

*

static USDVOL_API const TfTokenVector& GetSchemaAttributeNames ( bool includeInherited = true )

static

Return a vector of names of all pre-declared attributes for this schema class and all its ancestor classes.

Does not include attributes that may be authored by custom/extended methods of the schemas involved.

Member Data Documentation

const UsdSchemaKind schemaKind = UsdSchemaKind::AbstractTyped

static

Compile time constant representing what kind of schema this class is.

See Also: UsdSchemaKind

Definition at line 62 of file fieldBase.h.

The documentation for this class was generated from the following file:

pxr/usd/usdVol/fieldBase.h

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Member Functions

Friends

Detailed Description

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
